PRO-SS-1024-UPS_Intercom system

PRO-SS-1024-UPS

Performance. 1. Intechcom Pro-SS-1024-UPS Talkback Loudspeaker Stations operate in one channel modes . 2. Simultaneous talk and listen [full duplex] , when a gooseneck microphone is plugged into the front panel . 3. 50 Watt audio amplifier and quality

DETAILS

Performance.

1. Intechcom Pro-SS-1024-UPS Talkback Loudspeaker Stations operate in one channel modes .
2. Simultaneous talk and listen [full duplex] , when a gooseneck microphone is plugged into the front panel .
3. 50 Watt audio amplifier and quality loudspeaker provide highly intelligible reproduction .
4. Front panel controls provide a volume control which regulates the level of the loudspeaker or in the earspeaker in the headset/handset.
5. Main power switch(Front Panel)illuminated ,Indicates AC voltage present .
6. The‘ Call‘push button flashes a light in all outstations connected to your circuit. It is used to attract attention in the event that a user has removed his/her headset.
7. The ‘Talk’ button and turn up the ‘Listen level’ control on your unit and others on the same circuit as your - self ,you should now be able to communicate with any of these other outstations.
8. Dual power supply(DCV / Battery) with automatic change over function .
The Pro-SS1024UPS station allowing many beltpacks to be connected together without significantly changing the circuit performance. The termination networks are automatically removed and inserted during circuit linking to ensure a constant impedance for all circuits .

Technical Specifications:

·Ac power input: 85~264V.
·Power output: 24 volts DC regulated @ 2.5A continuous .
·Battery output: 24 volts @ 7A continuous .
·Power consumption : (At 220V/AC) 550W .
·Transducer impedances: Mic: 200 Ohms dynamic .
·Dimensions: (H x W x D): 110 x 320 x 230mm
·Weight: 2.6kg
